| TECHNICAL SPECIFICATIONS OF HEAVY DUTY SHREDDER MACHINE | ||||||||
|---|---|---|---|---|---|---|---|---|
| Model No | SC3051V | SC4002V | SC4003V | SC5005V | SC7507V | |||
| Feed Width (mm) | 305mm | 400mm | 400mm | 500mm | 750mm | |||
| Shred Size (mm) | 5mm | 5mm | 5mm | 5mm | 5mm | |||
| Shred Capacity (70 gsm A4 sheets) | 10-12 | 15-20 | 30 | 40 | 60-70 | |||
| Shred Capacity Per/Day | 500-600kgs/day | 800-1000kgs/day | 1000-1200kgs/day | 1500-2000kgs/day | 2500-3000kgs/day | |||
| Voltage | 230V /415V | 230V /415V | 230V /415V | 415V | 415V | |||
| Motor HP | 1HP | 2HP | 3HP | 5HP | 7.5HP | |||
| Motor HP-Compton make | SINGLE PHASEs | SINGLE PHASE | SINGLE PHASE | 3 Phase | 3 Phase | |||
| Motor HP-Hindustan make | 3 Phase | 3 Phase | 3 Phase | 3 Phase | 3 Phase | |||
| Speed (metres/minute) | 16mtrs/min | 16mtrs/min | 16mtrs/min | 16mtrs/min | 16mtrs/min | |||
| Cutter Diameter | 75mm | 75mm | 95mm | 117mm | 147mm | |||
| Weight (kgs) | 140kgs | 150kgs | 250kgs | 350kgs | 450kgs | |||
| Machines Dimensions (mm) | L 560X W 600 X H 1130 | L 660 x W 600 x H 1130 | L 750 x W 850 x H 1075 | L 850 x W 700 x H 1175 | L 1310 x W 900 x H 12 | |||
| Overload Protection | Yes | Yes | Yes | Yes | Yes | |||
| Motor On/Off | Online Starter | Online Starter | Online Starter | Online Starter | Online Starter | |||
| Duty Cycle | Continuous | Continuous | Continuous | Continuous | Continuous | |||
Katran Machine and other shredder machines from Raj Electricals are well known for their efficiency and robust make. Katran Machine or Paper Katran Machine is popular with Fruit Vendors as it is used during Fruit packaging. Katran Machine is a heavy-duty paper shredder machine and it is used to shred newspapers which is used in packing fruits.
This heavy duty shredder is used to reduce the volume of the rejected material and to avoid duplication and misuse and hence it has applications in numerous industries such as:
• Pharmaceutical Companies
• Label Printing Industries
• Paper Mills
• Packaging Industries
• Government Offices
• Colleges
• Banks
• Corporate Office
Salient Features of Katran Machine:
• Continuous Duty
• Motor with inline gearbox for positive transmission
• EFF2 Motor for less power consumption
• 5 Years warranty for cutters
• All Metal parts with Rugged construction
• Large waste collection trolley for shredding large volumes
• Overload &phase failure Protection
• Reverse forward switch 100
• Manufactured in India
• Custom-made manufacturing of superior quality products
• Installation and maintenance services on site
• User friendly
• Maintenance free
• Durable
• Smooth Operations
• High security level
• Low power consumption
We look forward to your inquiry for Katran Machine.
